X-ray System for Containers
"DDNDT" X-ray Inspection System for Containers is mainly used for testing steel cylinders, oxygen cylinders, and other pressured equipment. The system consists of a high-frequency mobile X-ray generator, a high-resolution industrial television system, a computer image processing system, a mechanical and electrical system, and a radiation protection system. It relies on X-ray characteristics of penetrating objects and storing images, which in turn carries out non-destructive inspection of pressured containers. The high degree of automation of the system, and high detection speed, greatly improve the efficiency of X-ray inspection.
Technical Specifications:
| Item | Origin | Model | Type |
| X-ray Tube | US Switzerland | 10-450kV | Metal Ceramic |
| High Voltage Generator | Imported China | Utility Frequency/ High Frequency/ Constant Frequency | 225KV |
| Control Console | China | DTK-1 | For Imported/ China Generator |
| Imported | US Switzerland | For Imported Generator | |
| Cooling System | China | Oil Cooling | 3010-4510 KV |
| Water Cooling | Less than 225KV | ||
| Generator Wheel Kits | China | U-Type | Hoisting |
| C-Type | Fixed | ||
| Customized | According to the actual situations | ||
| Imaging Device | China | Real-Time Imaging | 2D Graphics |
| China Imported | Flat Panel Imaging | 2/3D Graphics | |
| Mechanical Transmission System | China | 2D | Basic |
| 3D | Standard | ||
| 5D | Multi-Function | ||
| Protection System | China | Protection Room | Construction |
| Lead Room | Made of Lead | ||
| High Voltage Cable | Imported | 5-20M | HV Resistant |
| Image Processing System | China | DTK-2 | Human - computer Interaction |
| Detection Material | Steel, Copper/Copper Alloy Aluminium/Aluminium Alloy, Titanium/Titanium Alloy, Nickel/Nickel Alloy | ||
| Standard Penetration Thickness (mm) | Q235：2-250 | ||
